| FRD CODE | DIMNSION (mm) | WEIGHT(KG) | ||||||
| d | D | T | B | C | R min | r min | ||
| 326332 | 22 | 41 | 14.5 | 14.6 | 11.4 | 1 | 1 | 0.082 |
| 225H/41H | 22.5 | 41 | 12.4 | 11.2 | 8.6 | 0.6 | 0.6 | 0.063 |
| 24H/41H | 24 | 41 | 12.4 | 11.2 | 8.6 | 0.6 | 0.6 | 0.057 |
| 25M1/43Y1 | 25 | 43 | 11.1 | 11.2 | 8.3 | 0.6 | 0.6 | 0.06 |
| 25S/48YS | 25 | 48 | 15.8 | 15.1 | 10.9 | 1 | 0.6 | |
| 25Y/48YS | 25 | 48 | 15.2 | 14.3 | 11 | 1 | 0.6 | |
| 25YM/48Y | 25 | 48 | 13 | 12.5 | 9.2 | 1 | 0.6 | |
| 320/26X | 26 | 47 | 15 | 15 | 11.5 | 0.6 | 0.6 | 0.11 |
| N/H264815 | 26 | 48 | 15.2 | 14.3 | 10.9 | 1 | 0.6 | |
| 27S/48KS | 27 | 48 | 14 | 14 | 9.5 | 1 | 0.6 | 0.091 |
| 30K/48KS | 30 | 48 | 14 | 14 | 9.5 | 1 | 0.6 | 0.084 |
| 30Y/48KS | 30 | 48 | 15 | 15 | 9.5 | 1 | 0.6 | 0.086 |
| 30YM/48Y | 30 | 48 | 13 | 12.6 | 9.2 | 1 | 0.6 | 0.075 |
| 30YM1/48Y1 | 30 | 48 | 12 | 12.2 | 8.5 | 1 | 0.6 | 0.077 |
| N/H302014 | 30 | 50 | 14.4 | 14.8 | 10.7 | 1 | 1 | |
| 305115 | 30 | 51 | 15 | 14.8 | 11.4 | 1 | 1 | |
| 30KW/52K | 30 | 52 | 17 | 17 | 11.3 | 1 | 1 | 0.131 |
| CR-0643 | 30 | 52 | 16 | 16 | 11.5 | 1 | 1 | 0.134 |
| 34W/51W | 34 | 51 | 12 | 12 | 8 | 1 | 0.8 | |
